1. Multi functional practical machine, equipped with horizontal feeding movable handle
2. Multifunctional steel fixture, can copy various hollowness type,wave
type,cylindrical key and key for multi lock and composite bead keys and
some car keys,such as BMW,HONDA,Volkswagen car keys
3. Fixture with dark key duplication service pitch line and cylinder type key assembly function (multifunctional clamp)
4. With hardened ball bearing slide mechanism.
386A Key Copy Cutting Machine Reviews:
I bought a defu 368a key copy machine because really cheap and it works good on many types of key
How to Operate368A Key Copy Cutting Machine ?
The change of the cutter and leading needle:
1.Use inner hexagonal wrench to unclamp the regular screw anticlockwise direction.
2.Draw out the cutter and the lead needle downward,separate them from axis.
3.Insert the new cutter and leading needle in the axis,when suitable for
in its flexble position(Fig.1),fix the screw to lock in clockwise
direction with inner hexagonal wrench.
Note: Cutter and lead needle must the same angle(hole
type cut) or the same diameter(wave type cut), otherwise it is
inaccureate to duplicate.
368A Key Copy Cutting Machine Parameters:
Power: 220V/50hz
Dimension size: 30 *21*35cm
Weight: 10kg (Volume weight)
Voltage: 110V~220v
Frequency: 50/60Hz
Plug Type: UK.USA.BR.CN.EU
|
